VHF 10-keypad Tranceiver IC-F3230DT

---

FEATURES:

• IDAS™ Digital Mode Operation

• IP67 Waterproof and Dust-Tight Protection

• Easy to Hear in Noisy Areas

• Channel Announcement

• 8-Character LCD

• Roaming Scan

SPECIFICATIONS:

	IC-F3230DT/DS	IC-F4230DT/DS
Frequency coverage	136–174 MHz	350–400 MHz 400–470 MHz 450–512 MHz 450–520 MHz
Number of channels	128 channels/8 zones
Channel spacing (Varies according to version)	25*/12.5/6.25 kHz
Type of emission	16K0F3E*/11K0F3E/8K50F3E/4K00F1E/F1D
Current drain (approx.)	TX: 1.3A (High) RX: 400mA/100mA (Max. audio/Standby)
Dimensions (W×H×D) (projections not included)	53×120×37 mm; 2.09× 4.72×1.46 in (With BP-232WP)
Weight (approx.)	340g; 12oz (With MB-94R, BP-232WP & antenna)

Transmitter

	IC-F3230DT/DS	IC-F4230DT/DS
RF output power (at 7.5V DC)	5W, 2W, 1W (Hi, L2, L1)	4W, 2W, 1W (Hi, L2, L1)
Spurious emissions	75dB typ.
Frequency stability	±1.0ppm
Audio harmonic distortion	1.0/2.0% typ. (AF 1kHz 40% deviation, W/N)
FSK error	2% typ.
FM Hum and Noise	52/46dB typ. (W/N)	46/40dB typ. (W/N)

Receiver

		IC-F3230DT/DS	IC-F4230DT/DS
Sensitivity	(Analog 12dB SINAD)	0.23μV typ.	0.24μV typ.
	(Digital 5% BER)	0.18μV typ.	0.18μV typ.
Adjacent channel selectivity		TCP / IP, RS-422, NMEA 0183, Pelco D	74/67/58dB typ. (W/N/D)
Spurious response rejection		77/71/58dB typ. (W/N/D)	80dB typ.
Intermodulation rejection		75/75/70dB typ. (W/N/D)	76/76/72dB typ. (W/N/D)
Audio output power (at 5% distortion, 8Ω load)		1000mW typ. (Internal SP) 400mW typ. (External SP)
