VE-PG4 RoIP Gateway

---

FEATURES:

• All in One Package

• Call Recording to a USB Drive

• Microphone Connection for Base Operation

• Position and Status Information

• SIP Server and IP-PBX Functions

• Router Functions with VPN Tunnel

• Serial Pass-through Function

SPECIFICATIONS:

General

Operating humidity			5–95% (At no condensation)
Dimensions (W×H×D) (projections not included)			213 × 36.8 × 270 mm, 8.4 × 1.4 × 10.6 in (Approximate)
Power supply			12 V DC ±10%, 4 A maximum 100–240 V AC (with the supplied AC adaptor)
Operating temperature range			0°C to +40°C; +32°F to +104°F
Regulatory compliance			FCC Part 15 Class B/ ICES003, Part22, Part24, Part27, EN301 489-1, EN301 489-19, EN301 489-52, EN301 908-1, EN301 908-2, EN301 908-13, EN303 413, EN62479, EN62311, EN62368-1
Weight (approx.)			1.8 kg, 4 lb (Main unit, approximate)

Interface

LAN/WAN		RJ-45 type × 1 (Auto MDI/MDI-X) 10BASE-T/100BASE-TX/1000BASE-T *WAN/LAN port selectable.
LAN		RJ-45 type × 1 (Auto MDI/MDI-X) 10BASE-T/100BASE-TX/1000BASE-T
USB	Host interface	USB 3.0 Standard A receptacles ×3
	Console interface	USB 2.0 mini B receptacles ×1
External port	Connectors	2.54 mm (0.1 in) pitch quick connector (4 terminals ×3) ×4
	Audio input	–10 dBs/–40 dBs selectable Input impedance 10 kΩ unbalance
	Audio output	0 dBs/–20 dBs selectable 600 Ω load unbalance/8 Ω 1 W speaker
	Control input	Low voltage contacts (3.3 V DC/ 1 mA)/ Voltage input (3–16 V)
	Control output	No voltage contacts (30 V/ 100 mA)/ Open collector (3–16 V 10 mA)
Network*	4G bands:	LTE B1, B3, B7, B8, B20 (EUR) LTE B2, B4, B12 (FCC) LTE B1, B3, B5, B7, B8, B28 (AUS)
	3G bands:	W-CDMA B1, B8 (EUR) W-CDMA B2, B5 (FCC) W-CDMA B1, B5 (AUS)
