IC-SAT100 Satellite PTT

---

FEATURES:

• One-to-Many Communications

• Wide Area Global Communications

• Real-Time, Low-Latency Communication

• Built-in Emergency Key

• Waterproof, Dust-tight and Durable Body

• 1500 mW Powerful Audio

• Long Lasting Battery Life

• Private Conversation

• Conventional Radios and IP Phones Interconnection

SPECIFICATIONS:

General

			IC-SAT100
Dimemsions			57.8 × 135 × 32.8 mm, 2.3 × 5.3 × 1.3 in
Display (W×H×D) (projections not included)			33 × 27 mm, 1.3 × 1.1 in (viewing area)
Power supply requirement			13.75 V/27.5 V DC
Operational temperature range			–30°C to +60°C; –22°F to +140°F
Battery life (Approximate)			14.5 hours (TX : RX : standby = 5 : 5 : 90)
Antenna connector			SMA
Talkgroup			15 groups (Maximum)s
Audio output power
	Internal speaker		1500 mW typical (At 5% distortion into an 8 Ω load)
	External speaker		1000 mW typical (At 5% distortion into an 8 Ω load)
Weight (approx.)			360g, 12.7 oz (with BP-300 and antenna)
