IC-2730A Dual Band Transceiver

---

FEATURES:

• VHF/VHF, UHF/UHF Simultaneous Receive

• Optional VS-3 Bluetooth® Headset

• Easy-to-See Large White Backlit LCD

• Built-in 50 CTCSS and 104 DTCS tones with Split Tone Function

• 50 watts of output on VHF and UHF

• Wideband Receiver

SPECIFICATIONS:

General

Frequency coverage	USA Version	Transmit	144–148, 430–450MHz
		Receive	118–174, 375–550MHz*¹
	Export Version	Transmit	137–174, 400–470MHz*²
		Receive	118–174, 375–550MHz*²
No. of memory channels			1052 channels (including 50 scan edges and 2 Call)
Type of emission			F2D, F3E (FM, FM-N)
Power supply requirement			13.8V DC ±15%
Operating temperature range			–30°C to +60°C; –22°F to +140°F
Frequency stability			±2.5ppm
Antenna impedance			50Ω (SO-239)
Current drain (approx.)
	Tx		13A
	Rx		1.8A/1.2A (Max. audio/Stand-by)
Dimensions (W×H×D Projections are not included)
	Main unit		150×40×151 mm; 5.91×1.57×5.94 in
	Controller		150×50×27.2 mm; 5.91×1.97×1.07 in
Weight (approx.)
	Main unit		1.2 kg; 2.65 lb
	Controller		140 g; 4.94 oz

Transmitter

Output power (at 13.8V DC)		50W, 15W, 5W (TPE version: 25W, 15W, 5W)
Spurious emissions		Less than –60 dBc
Max. frequency deviation		±5.0kHz/±2.5kHz (W/N)
Microphone impedance		600Ω (8-pin modular)

Receiver

Intermediate frequencies	A band	38.85MHz/450kHz
	B band	46.35MHz/450kHz
Sensitivity (at 12dB SINAD)		Less than 0.18μV
Selectivity		More than 60dB/55dB (W/N)
Audio output power		More than 2W (10% dist. 8Ω)
Spurious response rejection	A band	More than 60dB/55dB (V/U)
	B band	More than 60dB/60dB (V/U)
External speaker connector		2 conductor 3.5 (d) mm (1/8″)/8Ω
Receiver sensitivity (Not guaranteed, for your reference only)	FM/FM-N (12dB SINAD)	137–159.995MHz*: Less than 0.32μV 160–174.000MHz: Less than 0.56μV 375–399.995MHz: Less than 0.56μV 400–499.995MHz*: Less than 0.32μV 500–550.000MHz: Less than 0.56μV
	AM/AM-N (10dB S/N)	118–136.991MHz: Less than 1μV
