F1100D IDAS™ VHF Transceiver

---

FEATURES:

• Icom’s Custom High Power Handling Capacity Speaker for 1500 mW of Powerful Audio

• Compact, Waterproof Durable Design (IP67/55/54 and MIL-STD-810-G)

• Optional 1500 mW Speaker-Microphone, HM-222HLWP*

• Multiple Operating Modes

• Over-the-Air Alias (OAA) Function Displays the Caller’s Name without Programming
  (IC-F1100DT/DS and IC-F2100DT/DS only)

• AquaQuake™ Function Clears Any Water Ingress That May Penetrate the Speaker Grill of the Unit

• Motion/Stationary Detection, Man Down and Lone Worker Functions

• IDAS™ Conventional and Type-D Single-Site Trunking

SPECIFICATIONS:

General

		IC-F1100DT/S	IC-F1100D	IC-F2100DT/S	IC-F2100D
Frequency coverage* (*Varies according to version)		136–174 MHz (NXDN/dPMR)		400–470 MHz (NXDN/dPMR USA/EUR/EXP) 450–512 MHz (NXDN, USA) 450–520 MHz (NXDN, EXP)
Number of channels		128 channels/ 8 zones	16 channels	128 channels/ 8 zones	16 channels
Type of emission* (*Depending onversion)		11K0F3E, 4K00F1E, 4K00F1D (USA)
		16K0F3E, 14K0F3E, 11K0F3E, 8K50F3E, 4K00F1E, 4K00F1D (EXP)
		16K0F3E, 14K0F3E, 8K50F3E, 4K00F1E, 4K00F1D (EUR)
Power supply requirement		7.5V DC nominal
Current drain (approx.)	Tx	1.3A		1.6 A (at 5 W) 1.4 A (at 4 W)
	Rx	520 mA /110 mA (Max. audio (internal SP)/Standby)		560 mA /140 mA (Max. audio (internal SP)/Standby)
Audio output		1 W (at 5% distortion)
Operating temperature range		–30°C to +60°C (Model with Lithium ion Battery Pack)
Dimensions (W x H x D)		58.5 x 130.5 x 37.5 mm
Weight		Approx. 310g (with BP-227 battery pack)
Construction		IP67, MIL-STD-810G
