360-DEGREE OMNI SCANNING SONAR CSH-10

---

FEATURES:

New “Tilt Indicator”

• Detection range up to an incredible 900 meters (over 2,900 feet)

• New “Tilt Indicator”

• "Beam stabilization” for clear and stable images in rough seas

• Superior resolution for more accurate underwater imaging

• “Fish estimate mark” measures fish school size

• Track schools of fish! “Target lock” function^*

• “Echo data recording and playback function” is useful for reviewing

• Intuitive new control unit

• Control the CSH-10 remotely (Optional)

• New transducer protective dome allows higher ship's speed allowance

SPECIFICATIONS:

General

Scanning	Full digital beam forming
Pixel number	1280 x 1024 (SXGA)
Basic Range	50?100?200?300?400?500?600?700?800?900?1000?1100?1200?1400?1600?2000 m

Display Unit

Pixel number	1280 x 1024 (SXGA)
Colors	32 colors (sonar pictures), 6 colors (marks)
Orientation	Head-up, North-up* and Course up* * Sensor required
Additional functions	Interference rejecter, Echo average, Noise limiter, Signal level, Automatic target tracking, Auto-retraction, Fish school alarm

Transceiver Unit

Pulse Length

0.5 to 20 ms













Hull Unit

Raising/Lowering time	7 s (400 mm travel), 10 s (600 mm travel)
Allowable Ship's Speed	20 kn (18 kn for raise/lower operation)
Transducer Travel	400 mm or 600 mm



Power Supply

Processor Unit	12-24 VDC: 4.0-2.0 A
Transceiver Unit	24 VDC, 7.2 A max
Hull Unit	24 VDC, 10 A max



Environment

Temperature	Processor/Transceiver unit: -15? to +55? Transducer: -5? to +35? Hull Unit: 0? to +55? Control Unit/Small Switch Box/Remote Controller: -15? to +55?
Relative humidity	93% or less at +40?
Waterproofing	Transducer: IPX8 Control Unit: IP22 (tabletop mount), IP25 (flush mount) Hull Unit: IPX2 Remote Control Unit: IPX4 (FSV-854-MK2), IP56 (SCU-001) Small Switch Box: IP56 (front), IP22 (rear)
